Supplier of Brass Butt Weld Fitting in India
Brass Buttweld Fittings are highly durable, corrosion-resistant components used across multiple industries due to their excellent mechanical properties. These fittings can easily withstand high temperatures, pressure, abrasion, and ensure a long-lasting, leak-proof connection. Crafted from high-quality brass alloys, they maintain their integrity over the years, even in challenging environments.
Products like the Brass Inverted Flared Fittings are commonly utilized in hydraulic brake systems and power steering setups, known for enhancing the efficiency of fluid delivery systems. These fittings are available in nickel finish, chrome-plated, or polished variants to meet aesthetic and performance demands.
ASTM B16 Brass Compression Fittings offer excellent malleability, making them easy to bend, mold, and weld. Their ease of installation and resistance to rust and wear help reduce operational costs while ensuring high performance. One such fitting, the C2600 Brass Tee, is commonly used to connect three different pipes and is popular in applications like ammunition, decorative furniture, and industrial components.
Other variants such as ASTM B283 Compression Elbow, brass male connector, brass nut, brass sleeve, and other accessories offer customization options like natural or nickel-plated finishes, depending on the client's needs.
Red Brass C23000 Ferrule Union is capable of handling a working pressure of up to 2000 PSI and an operating temperature between 65°F to 250°F. These fittings do not require tube flaring, making them cost-effective and simple to install. They are widely used in hydraulic systems, pneumatic instruments, and in applications that transport chemicals, water, flammable gases, and slurries.
With a typical life span of 80 to 100 years, Brass Transmission Fittings are a preferred choice for many industries. We offer a reliable supply of these fittings at competitive prices without compromising on quality or standards.
Specification of Brass Butt Weld Fittings
| Specification | Details / Grades | Available Types |
|---|---|---|
| Standard | MSS-SP-43, ASME/ANSI B16.9, ASME B16.28, BS4504, BS1560, BS10 |
|
| Grades | Brass C23000, C26000 | |
| Dimensions | MSS-SP-43, ASME B16.9, ASME B16.28, BS4504, BS10, BS1560 | |
| Size (Seamless) | ½” – 10” | |
| Size (Welded) | ½” – 48” | |
| Size Range | ½", 7/8" (DN15 – DN1200) | |
| Thickness | SCH10, SCH20, SCH30, STD, SCH40, SCH60, XS, SCH80, SCH100, SCH120, SCH140, SCH160, XXS | |
| Connection | Male Thread | |
| Type | DN15 – DN1200 | |
| Manufacturing Process | Push, Press, Forge, Cast, Hot / Cold Forming, Seamless, Welded | |
| Test Certificates |
EN 10204/3.1B, EN 10204/3.2 Raw Material Certificate 100% Radiography Test Report Third Party Inspection Report NACE MR0175 Compliant |
|
| Specialized In | 90º Elbows, 45º Elbows, Tees, Crosses, Reducers, Pipe Cap, Stub End, Pipe Bends | |
| Applications | Hydraulic Systems, Water Lines, Power Steering, Instrumentation, Decorative Use, Oil & Gas | |
| EIL & IBR Approved Fittings | ||
Types of Buttweld Fittings
Explore our precision-engineered Buttweld Fittings designed for leak-proof and high-strength piping systems.
Buttweld Elbow
Elbows allow directional changes in piping systems, available in 45°, 90°, and 180° bends for smooth fluid flow with minimal pressure loss.
Buttweld Tee
Tees are used to split or combine flow in pipelines, offered in equal and reducing types for
multiple outlet configurations.
Buttweld Reducer
Reducers transition between pipe sizes, available in concentric (center-aligned) and eccentric (offset) types to manage flow and avoid turbulence.
Buttweld Cap
End caps are used to block the end of a piping system, providing secure sealing in high-pressure and high-temperature conditions.
Buttweld Stub End
Stub ends are used with lap joint flanges, making them ideal for systems requiring frequent dismantling for inspection or maintenance.
Buttweld Nipple
Nipples are short pieces of pipe with bevelled ends used for connecting fittings, valves, or
other equipment in tight spaces.
Pressure Rating of ASTM B16 Brass Compression Fittings
| OD Size | PSI | Bar |
|---|---|---|
| 1/8" | 3045 | 210 |
| 3/16" | 3045 | 210 |
| 1/4" | 3045 | 210 |
| 5/16" | 3045 | 210 |
| 3/8" | 2030 | 140 |
| 1/2" | 1522 | 105 |
| 5/8" | 1522 | 105 |
| 3/4" | 1015 | 70 |
| 1" | 1015 | 70 |
Fittings Size
| Nominal Pipe Size |
Outside Diameter |
90° Elbows | 45° Elbows | 180° Returns | ||||
|---|---|---|---|---|---|---|---|---|
| (inches) | Long Radius | Short Radius | Long Radius | Long Radius | ||||
| (mm) | (inches) | Center to Face (inches) |
Center to Face (inches) |
Center to Face (inches) |
Radius (inches) |
Center to Center (inches) |
Back to face (inches) |
|
| 1/2 | 21.3 | 0.840 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 18 | 12 | 7 1/2 | 18 | 36 | 24 3/8 |
Features & Benefits
Our Brass Buttweld Fittings are precision-engineered to offer superior performance in plumbing, industrial, and fluid-handling systems. With excellent corrosion resistance, durability, and a broad range of configurations, these fittings are ideal for both low and high-pressure applications. They are designed to meet global specifications and are available in multiple connection types for seamless integration.
- Corrosion-Resistant Alloy – Brass construction ensures long life and reduced maintenance.
- Excellent Machinability – Ideal for forming, bending, and threading.
- Durable in Varying Environments – Performs reliably in industrial, commercial, and residential setups.
- Customizable Size & Thickness – Available in SCH10 to XXS for application-specific demands.
- Leak-Free Connections – Secure male thread connections ensure tight seals under pressure.
- Size Range from 1/2" to 7/8" – Flexible options for different pipelines.
- Meets Global Standards – Compliant with ASME, MSS-SP, BS1560, and BS4504.
- Pressure Rated PN25 – Suitable for medium-pressure applications.
- Broad Range of Fitting Types – Including Elbows, Tees, Caps, Bends, and more.
- Ideal for Water & Gas Systems – Trusted in HVAC, plumbing, and process industries.
