High Nickel Alloys Pipes and Tubes Supplier in India
High Nickel Alloy Pipes & Tubes are engineered to deliver exceptional performance in extreme environments where conventional materials fail. These alloys offer superior resistance to high temperatures, oxidation, corrosion, and aggressive chemical exposure, making them ideal for critical applications in industries such as aerospace, chemical processing, marine engineering, nuclear power, and oil & gas. At Vardhman Steel Overseas, we supply a comprehensive range of Nickel Alloy Pipes and Tubes available in seamless, welded, and fabricated forms, manufactured as per global standards.
We stock and export various high-performance grades including Inconel 600, 601, 625, 718, known for their strength and resistance to heat and corrosion. Our Hastelloy grades such as C276, C22, and B2 are widely used in aggressive chemical media and oxidizing environments. We also offer Monel 400 and Monel K500, which are highly effective in marine and saltwater applications due to their excellent corrosion resistance. For high-temperature and acidic applications, our Incoloy 800, 800H, 800HT, and 825 pipes and tubes provide long-lasting stability and performance.
Each material is selected and tested to meet stringent international standards such as ASTM, ASME, DIN, and EN. These Nickel Alloy Tubes & Pipes are available in multiple sizes, schedules, and forms to meet custom requirements for challenging applications. With excellent weldability, mechanical strength, and resistance to pitting and stress corrosion cracking, our high nickel alloy products ensure reliability and efficiency in the most demanding industrial systems.
High Nickel Alloys Pipes & Tubes Specification
| Specifications | Details |
|---|---|
| Grades |
Inconel: 600, 601, 625, 718 Hastelloy: C276, C22, B2 Monel: 400, K500 Incoloy: 800, 800H, 800HT, 825 |
| Standard | ASTM, ASME, DIN, EN, JIS, ISO, NACE |
| Pipe Types | Seamless, Welded, ERW, EFW, Fabricated |
| Form | Round, Square, Rectangular, Coiled, Hydraulic, “U” Shape, Hollow, Straight Tubes |
| End | Plain End, Beveled End, Threaded |
| Size Range | 6.35 mm OD to 254 mm OD |
| Thickness | 0.3 mm – 50 mm |
| Length | Single Random, Double Random, Custom Cut Lengths |
| Schedule | SCH 5, 10, 20, 40, 60, 80, 120, 160, XXS |
| Finish | Annealed & Pickled, Bright Annealed (BA), Polished, Mill Finish (MF) |
| Marking | Standard, Grade, Size, Thickness, Heat No., Manufacturer (or as per customer requirement) |
| Testing & Documentation | MTC as per EN 10204 3.1 / 3.2, PMI Test, IGC Test, Hydro Test, Third Party Inspection if required |
| Applications | Oil & Gas, Petrochemical, Chemical Processing, Power Plants, Heat Exchangers, Aerospace, Marine |
Types of Pipes & Tubes
Explore our wide range of high-performance Pipes & Tubes manufactured in various grades and materials.
Seamless Pipes & Tubes
Seamless pipes offer superior strength and corrosion resistance, ideal for high-pressure and high-temperature applications.
Welded Pipes & Tubes
Cost-effective and durable, welded pipes are suitable for structural and low-pressure applications across various industries.
ERW Pipes & Tubes
ERW (Electric Resistance Welded) pipes are widely used for transportation of oil, gas, and water due to their precision and strength.
Electropolished Pipes
Electropolished pipes feature ultra-smooth surfaces for hygienic applications in the pharmaceutical, food, and biotech industries.
EFW Pipes
EFW (Electric Fusion Welded) pipes are preferred for large-diameter applications such as
offshore and structural pipelines.
Pipe Dimensions and Schedules
Pipes come in various sizes and schedules to accommodate the specific pressure requirements of the application. Below is a detailed table that outlines the dimensions for the most common pipe schedules:
Nominal Broe |
Outside Diameter |
Schedule 5S |
Schedule 10S |
Schedule 40S |
Schedule 80S |
Schedule 160S |
Schedule XXS |
|||||||
mm |
INCH |
mm |
Wt mm |
Weight (Kg/mt) |
Wt mm |
Weight (Kg/mt) |
Wt mm |
Weight (Kg/mt) |
Wt mm |
Weight (Kg/mt) |
Wt mm |
Weight (Kg/mt) |
Wt mm |
Weight (Kg/mt) |
3 |
1/8 |
10.3 |
1.24 |
0.276 |
1.24 |
028 |
1.73 |
0.37 |
2.41 |
0.47 |
- |
- |
- |
- |
6 |
1/4 |
13.7 |
1.24 |
0.390 |
1.65 |
049 |
2.24 |
0.631 |
3.02 |
.0.80 |
- |
- |
- |
- |
10 |
3/8 |
17.1 |
1.24 |
0.490 |
1.65 |
0.63 |
2.31 |
0.845 |
3.20 |
1.10 |
- |
- |
- |
- |
15 |
1/2 |
21.3 |
1.65 |
0.800 |
2.11 |
1.00 |
2.77 |
1.27 |
3.75 |
1.62 |
4.75 |
1.94 |
7.47 |
2.55 |
20 |
3/4 |
26.7 |
1.65 |
1.03 |
2.11 |
1.28 |
2.87 |
1.68 |
3.91 |
2.20 |
5.54 |
2.89 |
7.82 |
3.63 |
25 |
1 |
33.4 |
1.65 |
1.30 |
2.77 |
2.09 |
3.38 |
2.50 |
4.55 |
3.20 |
6.35 |
4.24 |
9.09 |
5.45 |
32 |
1.1/4 |
42.2 |
1.65 |
1.65 |
2.77 |
2.70 |
3.56 |
3.38 |
4.85 |
4.47 |
6.35 |
5.61 |
9.70 |
7.77 |
40 |
1.1/2 |
48.3 |
1.65 |
1.91 |
2.77 |
3.11 |
3.68 |
4.05 |
5.08 |
5.41 |
7.14 |
7.25 |
10.16 |
9.54 |
50 |
2 |
60.3 |
1.65 |
2.40 |
2.77 |
3.93 |
3.91 |
5.44 |
5.54 |
7.48 |
8.74 |
11.1 |
11.07 |
13.44 |
65 |
2.1/2 |
73.0 |
2.11 |
3.69 |
3.05 |
5.26 |
5.16 |
8.63 |
7.01 |
11.4 |
9.53 |
14.9 |
14.2 |
20.39 |
80 |
3 |
88.9 |
2.11 |
4.51 |
3.05 |
6.45 |
5.49 |
11.30 |
7.62 |
15.2 |
11.1 |
21.3 |
15.24 |
27.65 |
100 |
4 |
114.3 |
2.11 |
5.84 |
3.05 |
8.36 |
6.02 |
16.07 |
8.56 |
22.3 |
13.49 |
33.54 |
17.12 |
41.03 |
125 |
5 |
141.3 |
2.77 |
9.47 |
3.40 |
11.57 |
6.55 |
21.8 |
9.53 |
31.97 |
15.88 |
49.11 |
19.05 |
57.43 |
150 |
6 |
168.3 |
2.77 |
11.32 |
3.40 |
13.84 |
7.11 |
28.3 |
10.97 |
42.7 |
18.2 |
67.56 |
21.95 |
79.22 |
200 |
8 |
219.1 |
2.77 |
14.79 |
3.76 |
19.96 |
8.18 |
42.6 |
12.7 |
64.6 |
23.0 |
111.2 |
22.23 |
107.8 |
250 |
10 |
273.1 |
3.40 |
22.63 |
4.19 |
27.78 |
9.27 |
60.5 |
12.7 |
96.0 |
28.6 |
172.4 |
25.40 |
155.15 |
300 |
12 |
323.9 |
3.96 |
31.25 |
4.57 |
36.00 |
9.52 |
73.88 |
12.7 |
132.0 |
33.32 |
238.76 |
25.40 |
186.97 |
350 |
14 |
355.6 |
3.96 |
34.36 |
4.78 |
41.3 |
11.13 |
94.59 |
19.05 |
158.08 |
35.71 |
281.70 |
- |
- |
400 |
16 |
406.4 |
4.19 |
41.56 |
4.78 |
47.29 |
12.7 |
123.30 |
21.41 |
203.33 |
40.46 |
365.11 |
- |
- |
450 |
18 |
457.2 |
4.19 |
46.80 |
4.78 |
53.42 |
14.27 |
155.80 |
23.8 |
254.36 |
45.71 |
466.40 |
- |
- |
500 |
20 |
508.0 |
4.78 |
59.25 |
5.54 |
68.71 |
15.09 |
183.42 |
26.19 |
311.2 |
49.99 |
564.68 |
- |
- |
600 |
24 |
609.6 |
5.54 |
82.47 |
6.35 |
94.45 |
17.48 |
255.41 |
30.96 |
442.08 |
59.54 |
808.22 |
- |
- |
Features & Benefits
Our premium range of High Nickel Alloy Pipes & Tubes is engineered to withstand the most corrosive and high-temperature environments. At Vardhman Steel Overseas, we deliver reliable solutions using top-grade materials like Inconel, Hastelloy, Monel, and Incoloy.
- Exceptional Corrosion Resistance – Ideal for aggressive chemical environments.
- High Temperature Strength – Performs efficiently under extreme thermal conditions.
- Oxidation Resistance – Reliable in high-pressure and high-temperature systems.
- Excellent Mechanical Properties – Delivers high tensile and yield strength.
- Versatile Applications – Suitable for aerospace, power, marine, and chemical industries.
- Available in Multiple Grades – Inconel 600, 625, 718, Hastelloy C22, C276, Monel 400, K500, Incoloy 800, 825.
- Excellent Fabrication & Weldability – Supports various forming and welding methods.
- Superior Fatigue Strength – Withstands stress and load fluctuations over time.
- Custom Sizing & Finishing – Available in polished, annealed, and pickled finishes.
- Standards Compliant – Meets ASTM, ASME, ISO, NACE, and other global standards.
