Durable Chequered Plates for Anti-Slip Flooring & Structural Applications
Vardhman Steel Overseas supplies high-performance Chequered Plates that offer excellent grip, durability, and structural strength. These plates feature a raised pattern (commonly tear-drop or diamond) on the surface, making them ideal for applications where anti-slip and wear resistance are essential.
Our Chequered Plates are widely used in Industrial Flooring, Truck Beds, Stair Treads, Walkways, Platform Structures, Ramps, and Heavy Machinery Areas. The unique textured surface provides enhanced traction and safety, especially in wet or oily environments.
We manufacture Chequered Plates in compliance with standards such as IS 3502, ASTM A786, EN 10029, and BS 1449. Available in thicknesses ranging from 3 mm to 12 mm, widths up to 1500 mm, and lengths up to 6000 mm. Custom sizes and patterns are also available based on project requirements.
Each plate undergoes stringent quality checks for pattern uniformity, dimensional accuracy, and load-bearing capacity. We provide complete Mill Test Certificates and optional Third-Party Inspection services through BV, TUV, DNV, and Lloyds.
Choose Vardhman Steel Overseas for premium-grade Chequered Plates that combine safety, strength, and long service life in rugged industrial conditions.
Available Materials & Grades
Our Chequered Plates are manufactured in a range of robust and corrosion-resistant materials to suit varied load, environmental, and safety requirements.
| Material Type | Common Grades |
|---|---|
| Carbon Steel | IS 2062, ASTM A36, A283 |
| Stainless Steel | 304, 304L, 316, 316L, 409 |
| Aluminium | 3105, 5052, 6061 |
Chequered Plates – Technical Specifications
Explore the technical specifications of our Chequered Plates designed for maximum safety and reliability in high-traffic areas.
| Specification Parameter | Details |
|---|---|
| Product Name | Chequered Plate / Tread Plate |
| Thickness Range | 3 mm to 12 mm |
| Width | Up to 1500 mm |
| Length | Up to 6000 mm (custom sizes available) |
| Pattern Type | Tear Drop, Diamond, Five Bar, Customized |
| Manufacturing Method | Hot Rolled / Cold Rolled (for stainless & aluminum) |
| Applicable Standards | IS 3502, ASTM A786, EN 10029, BS 1449 |
| Testing & Certification | Dimensional & Surface Checks, Load Testing, MTC as per EN 10204 3.1 / 3.2, TPI available |
Features & Benefits
Chequered Plates from Vardhman Steel Overseas combine structural integrity with enhanced safety and usability, making them a reliable choice for both industrial and commercial flooring solutions.
- Anti-Slip Surface – Raised patterns offer excellent grip and slip resistance.
- High Load Capacity – Ideal for platforms, ramps, and heavy machinery floors.
- Corrosion-Resistant Grades – Available in stainless and aluminum for wet and chemical-exposed areas.
- Robust & Durable – Engineered to withstand impact, wear, and harsh conditions.
- Maintenance-Free – Easy to clean, long-lasting performance with minimal upkeep.
- Customizable Dimensions – Available in custom cuts, patterns, and lengths for project-specific needs.
- Multiple Material Options – Carbon steel, stainless steel, and aluminum to suit every environment.
- Enhanced Safety – Used in walkways, steps, and vehicles to reduce the risk of accidents.
- Compliance with Global Standards – Meets IS, ASTM, BS, and EN specifications.
- Ready Stock Availability – Rapid delivery with bulk inventory for ongoing and urgent projects.
